Garmin announces availability of visual approach guidance for the GTN 650/750

Download: Printable PDF Date: 09 Nov 2017 04:18 categories:
Publisher:
Garmin announces availability of visual approach guidance for the GTN 650/750 - Manufacturer publisher
Krista Kuznecova
Country: United States Aircraft: Airplanes

Garmin is pleased to announce the latest software upgrade for the GTN 650/750 touchscreen series is now available. New GTN features include visual approach guidance, control and display of the GTX 3000 transponder and GTS 8000 Traffic Alert and Collision Avoidance System (TCAS II)/Airborne Collision Avoidance System (ACAS II), as well as LNAV+V approaches without Space-Based Augmentation System (SBAS) service. These new features bring advanced capabilities and even more functionality to new and existing GTN 650/750 navigators.

Visual approach guidance

Visual approach guidance is now available within the GTN 650/750, which provides advisory vertical guidance in visual flight conditions based on a published glide path angle or a three-degree glideslope from the threshold of the runway, while considering terrain and obstacle clearance. When selecting a visual approach, pilots can choose the runway of intended landing and select vectors for the final approach intercept to assist them in flying a stabilized approach. When a flight plan is loaded, the GTN will also provide a short cut to optionally load and activate a visual approach when the aircraft is within 5 miles of the destination airport if an approach is not already selected. By utilizing visual approach guidance within the GTN, pilots are provided a more stable descent and precise flight path throughout the approach and landing phases of flight while operating in visual conditions.

LNAV+V approaches without WAAS/SBAS

Pilots operating into airports throughout the world that are not served by WAAS/SBAS can now receive advisory vertical guidance (LNAV+V) while flying LNAV approaches with the GTN 650/750. By taking advantage of the advisory glideslope offered by the GTN, pilots can more easily fly a stabilized descent while flying LNAV approaches.

ADS-B capability for TCAS II-equipped aircraft

Aircraft equipped with select third-party TCAS II/ACAS II systems can pair a GTN 650/750 navigator with a GTX 3000 Mode S ES transponder, which now offers display and control capability, as well as a simplified and economical path to ADS-B compliance and WAAS/LPV approaches. Additionally, GTN navigators can display and control the GTS 8000 TCAS II/ACAS II system from the touchscreen display. Traffic information is overlaid on the moving map, as well as the dedicated traffic page. When paired with the GTS 8000, Garmin’s patented TargetTrend technology provides pilots with a more intuitive method of judging traffic trajectories and closure rates. The integration of Garmin’s patented CLEAR CAS (Correlated Location Enhanced ADS-B Receiver Collision Avoidance System) also uses a blended surveillance method of active interrogation and passive reception of 1090 Extended Squitter (ES) ADS-B data, reducing active interrogations by using intruder position data received via ADS-B-equipped aircraft.

Improved Connext interface

Aircraft that are equipped with a GTN 650/750, GTX 345 all-in-one ADS-B transponder and Flight Stream 510, can now receive attitude information through a single Bluetooth® connection via Flight Stream 510.

These new features and capabilities for the GTN 650/750 are available immediately for hundreds of fixed-wing aircraft makes and models. The GTN software upgrade is supported by Garmin’s award-winning aviation support team, which provides 24/7 worldwide technical and warranty support. For additional information, visit www.garmin.com/aviation.
